Sensori
|
Temperature sensors
Thecnical characteristics
|
mod. |
SON96V.015MT |
SON96V.011MT |
SON96V.007MT |
Type: |
PT100 3 fili |
PT100 3 fili |
PT100 3 fili |
Class: |
B |
B |
B |
Degree protection : |
IP65 |
IP65 |
IP65 |
Response time :. |
120 sec. |
120 sec. |
120 sec. |
Dimensions: |
6 x 50 mm |
6 x 50 mm |
6 x 50 mm |
Cable length : |
15 meters |
11 meters |
7 meters |
Temperature and humidity sensors
Thecnical characteristics
|
mod. HU-HPCF-10 |
Temperature |
Humidity |
General |
Type: |
PT100 3 fili |
Capacitiva |
|
Accuracy: |
cl. B (+/- 0,3%) |
+/- 3,5% da 0/100% |
|
Field of measure : |
-60°C / +60°C |
0/100% Rh |
|
Response time : |
< 120 sec. |
> 300 sec. |
|
Output signal : |
0,00385 ohm/ohm/°C |
0,8 / 4V |
|
Connector:: |
Terminal R/C/C |
Terminal +/-/Vout |
|
Field of use : |
-40/+85 °C |
0/60 °C (0/100% RH) |
|
Supply : |
|
9/40 Vdc |
|
Absorbed current |
|
1,5/4,5 mA |
|
Load impedence |
|
> 5000 ohm |
|
Degree of protection |
|
|
IP30 |
Dimensions |
|
|
30 x 185 mm |
Cable length : |
|
|
10 meters (tip.) |
CO2 Sensor
Thecnical characteristics
|
mod. CO2-SENS1 |
CO2 |
|
|
Type: |
NDIR |
|
|
Accuracy: |
+/- 100 ppm |
|
|
Field of measure : |
0 / 4975 ppm |
|
|
Response time : |
< 5 min. |
|
|
Output signal : |
4/20mA |
|
|
Connector:: |
Terminal +/-/Vout |
|
|
Field of use : |
-40 / +85 °C |
|
|
Supply : |
10/31 Vdc |
|
|
Absorbed current |
|
|
|
Load impedence |
< 300 ohm |
|
|
Degree of protection |
IP30 |
|
|
Dimensions |
*** TBD |
|
|
Cable length : |
10 meters (tip.) |
|
|
|
|
|
|
